编码器iCs
品牌:
iC-haus
型号:
iC-TW4 QFN24 4x4
封装:
预计交期:
大陆:5~7   香港:7~14
库存数量:
150
  • 产品详情
  • 产品参数
  • 规格书
  • 关联产品

可编程8位正余弦插补细分器, 带 EEPROM

Features

  • Interpolation rate fully programmable from 1 to 256 steps per cycle

  • Latency less than 500 ns

  • Direct sensor connection, selectable input gain, input signal 10 mV to 1.5 V peak-peak differential

  • Max input frequency 460 kHz at interpolation rate <= 64, 230 kHz <= 115="" khz=""> 128

  • Differential index gating input with fine adjustable offset (single ended by connection to VC)

  • Output modes quadrature ABZ, up/down, increment/direction or 3 phase commutation

  • Programmable filter and hysteresis

  • Fully re-programmable with access to internal E2PROM to store setup and customer data


Applications

  • Interpolator iC for position data acquisition from analog sin/cosine sensors

  • Optical linear/rotary encoders

  • Magneto resistive (MR) sensors/encoders
